Tesla Wall Connector
Installation. Done Right.
Charge at full 48A speed from day one. Certified electricians handle your panel, 60A circuit, ESA permit, and Tesla app setup in a single visit.
Tesla Wall Connector Install
We confirm your panel capacity and call back within 2 hours.
Built for your Tesla. Installed by experts.
Permit to Wi-Fi - everything in one visit
Wall Connector vs. every alternative
Wall Connector Best for Tesla | Generic Level 2 | 120V Outlet | |
|---|---|---|---|
| Max charge rate | 48A / 11.5 kW | 32-40A / 9.6 kW | 12A / 1.4 kW |
| Range per hour | Up to 72 km | 35-55 km | 8-10 km |
| Model Y full charge | ~7 hours | 9-12 hours | 40+ hours |
| Tesla app integration | Native | Limited | None |
| Power sharing | Yes - up to 4 units | No | No |
| Indoor and outdoor rated | Yes (NEMA 4) | Varies | Indoor only |
Every Tesla. Full speed.
Tesla owners across the GTA
Booked on a Tuesday, installed Thursday. The electrician knew exactly how to set up the power sharing between our two Wall Connectors. Both cars are fully charged every morning. Couldn't be easier.
Had a 100A panel and was worried I'd need a full upgrade. They installed the EVEMS load management system instead and saved me about $3,000. Wall Connector charges at 32A overnight - more than enough.
Very professional. They handled the ESA permit, ran clean conduit along the garage wall, and had the Gen 3 connected to my Wi-Fi before they left. The whole job took under 4 hours.
I called three electricians. EV Install Pro was the only one who actually understood how the Wall Connector power sharing worked. Installed two units for our garage on a single 60A circuit. Zero issues.
Common questions
Do I need a Tesla-certified installer?
Tesla does not strictly require a certified installer for the Wall Connector, but using one ensures the installation meets Tesla wiring specifications, the charger is correctly configured, and any warranty issues are handled properly. We are Tesla-certified and familiar with every Wall Connector generation.
Which Wall Connector generation do I have?
The Gen 3 Wall Connector (current) has a sleek white rectangular design with a 24-foot cable and supports up to 48A (11.5 kW) on a 60A circuit. Gen 2 units are slightly bulkier and support up to 40A. We install and configure both.
Can I link multiple Wall Connectors?
Yes. Tesla Gen 3 Wall Connectors support power sharing between up to 4 units on a single circuit - ideal for two-Tesla households or multi-bay garages. We handle all wiring and pairing configuration.
What circuit size do I need?
Tesla recommends a 60A dedicated circuit for maximum 48A charging. A 50A circuit limits to 40A and a 40A circuit limits to 32A. We assess your panel and recommend the right circuit size during your free quote.
Will it work with my 100A panel?
Yes, with smart load management. Our EVEMS (DCC-12) monitors your home total electrical load and adjusts Wall Connector output in real time. Most 100A panel homes charge at 24A to 32A continuously without a panel upgrade.
How does overnight scheduling work?
The Tesla app handles charge scheduling directly on the car - the Wall Connector does not need separate programming. We verify the Wi-Fi connection and app pairing during installation so everything works from day one.
Ready to charge at full speed?
Same-week installation across Toronto, Mississauga, Vaughan, Markham, Richmond Hill, Oakville, and all of the GTA.
